Usage: | Electronic |
Material: | DMC, Copper |
Installation: | Cut out |
Type: | Auto Fuse Holder |
Shape: | Square |
Size of Fuse: | 82mm |
Basic Info.
Model NO.: CEC-400
Form of Installation: Bolted
The Fuse Holder for Environmental Protection is a crucial component in safeguarding the environment from potential hazards. This device plays a key role in protecting electrical devices from overloading, short-circuiting, and other electrical malfunctions that can harm the environment. With its advanced features, this fuse holder ensures that electrical equipment operates safely and in an eco-friendly manner. In today's world, environmental protection is of utmost importance, and the fuse holder for environmental protection is a valuable tool in achieving this goal. By utilizing this device, we contribute to a better and cleaner world while also ensuring the safety of our electrical infrastructure. Let's join hands in safeguarding the environment by incorporating such green technologies into our daily lives.
Execution Standard: BS
Fusing Speed: F
Brand: Cowinelec
Transport Package: Foam Safety Boxes
Specification: Max 415A
Trademark: Cowinelec
Origin: Wenzhou, China
HS Code: 85361000
Production Capacity: 20000sets/Month
Product Description
Cutout Fuse and base
The J wedge fuse conforms to the standards of GB13539, IEC60269 and BS88. To produce a similar text, the information in the original content must be reorganized while maintaining its meaning.
This versatile product has been specifically designed to provide maximum protection against overloads and short circuits in distributing lines. With a rated voltage of 415V and a rated current capacity of up to 415A at an AC frequency of 50Hz, it offers reliable and efficient performance. Its primary function is to safeguard the integrity of the electrical distribution system by instantly detecting and mitigating any potential issues. Whether it's in industrial or residential settings, this product ensures the smooth and uninterrupted flow of electricity, promoting safety and preventing costly damage. Trust this exceptional device for comprehensive overload and short circuit protection in your distributing line.
Technical Data
Rated voltage: 415V AC
Breaking capacity: 80KA
Function grade: gG /gL/gtr/aM/gM
Type | Spec | Competitor part number | Rated voltage (V) | Class rating (A) | Dimensions (mm) | |||||||||||
A | B | C | D | E | F | G | H | I | J | K | L | |||||
J | 82 | CECJ | 415 | 32~200 | 110 | 82 | 45.2 | 40.5 | 30 | 14.8 | 18 | 6.5 | 2.4 | 17.5 | 9.8 | 30.8 |
J | 82 | CECJ | 415 | 200~400 | 110 | 82 | 44.8 | 40 | 30 | 14.4 | 18 | 6.5 | 2.4 | 17.5 | 9.8 | 38 |
J | 92 | CECJ | 415 | 20~315 | 131 | 92 | 46.8 | 40.5 | 41 | 17.4 | - | 8.7 | 3.2 | 20.7 | 11 | 30.8 |
J | 92 | CECJ | 415 | 355~400 | 131 | 92 | 46.4 | 40 | 41 | 17.4 | 24 | 8.1 | 3.2 | 20.7 | 10 | 38 |
J | 92 | CECJ | 415 | 315~500 | 131 | 92 | - | 45 | 38 | 16.5 | 22 | 8 | 3.2 | 20.6 | 11 | 50 |
J | 92 | CECJ | 415 | 560~630 | 129 | 92 | 44.5 | 47.8 | 38 | 16.5 | 22 | 8 | 3.2 | 20.6 | 11 | 73.3 |
CEC-400
400A Fuse cut-out for pole or wall mounting c/w M12 coach screw.
Structure Feature
Vandal resistant tough design, using our own formulation of GRP.
Slide fit front cover for ease of jointing.
'Easy fit' studs accept cable sockets (lugs) up to 300mm².
Designed to accept standard 'J' type fuse links
Compliant with the requirements of BS7656:1993
Compliant with the design criteria of IP43
Fuse Links
This fused Cut-out is designed to accommodate standard wedge type fuse links to BS88-5:1988, conform to 415AC80.
Fixing centre requirement is 82mm.
Standard fuse link rating range from 20A to 400A.
